- Max. Cutting Size: 2500mm x 1600mm
- Tools: Variuos cutting blades; different size of creasing wheels
- Moving speed : Up to 1500mm/s
- Cutting speed: Up to 1200mm/s (depend on the kind of material)
- Rated Power: 9.5 KW
- Rated voltage: 380V/220V+-10%; 50Hz / 60 Hz
- Cutting material: All kind of corrugated paperboard; Grey board; KT Board; PVC expansion sheet; honeycomb board; car sticker; light slide; PP gum; Flex banner; Flag fabric; EPE Foam; EVA; PVC plate; Acrylic; Thick foam; etc
- Machine size: 3650x2620x1280mm
- Unit utama
Rated Power 9.5KW Multi-functional Machine Head Easy to change different tools. Oscillating thorough cutting/Kiss Cutting/Creasing/Plotting/Laser positioning and precise camera registration Moving Speed Up to 1500 mm/s Tools Various kinds of cutting blades, different sixe of creasing wheels Cutting Material All kinds of corrugated paperboard, Grey board, KT Board, PVC expansion sheet, honeycomb board, car sticker, light side, PP gum, Flex banner, Flag fabric, EPE Foams, EVA, PVC Plate, Acrylic, Thick foam etc Safety Device Infrared sensor, responsive, safe and reliable Machine Size 3650 x 2620 x 1280 mm Numerical Control Panel Multi Language LCD Touch Screen Max Cutting Size 2500 x 1600 mm Interface Ethernet Port Rated Voltage 380C/220C+/-10%; 50/60 Hz Repeatability +/- 0.05 mm Cutting Speed Up to 1200 mm/s (Depends on different Materials) Transmission Imported (Digital servo motor, straight rail, synchronous belt, guide screw) Cutting Material Affixed Smart(optional) individual multi-zone vaccum suction Cutting Thickness </=50 mm (Customize according to different Materials)
